Blue-Thunder® 403

Stick Welding Power Source

Blue-Thunder® 403 ​

029 016 234





Industrial SMAW System with:

  • Large, welding parameter display
  • EZ-set, amperage control
  • Electrode diameter guide
  • Lifting Eyelets
  • Heavy Duty Running gear
  • Handle/cable carrier
  • Robust reliable construction.





 SPECIFICATIONS





PRODUCT LITERATURE

 Blue-Thunder® 403 - English



PROCESSES

Stick (SMAW) TIG (GTAW)



GENERAL SPECIFICATIONS

Title

Blue-Thunder® 403

Applications

Mining Fabrication
Structural Fabrication
Trailer Fabrication
Container Repairs
Maintenance Repair

Input Voltage

230 V - 400 V

Input Hz

50 Hz

Input Phase

3-Phase

Input Amperage

3 Phase – 400 A at 36 VDC, 35% duty cycle

Stick (SMAW)

60-400 A

TIG (GTAW)

60-400 A

Weld Output

CC



Net Width

410 mm (16.15 in)

Net Height

650 mm (2.56 in)

Net Length

980 mm (38.59 in)

Net Weight

115 kg (253.54 lbs)





 FEATURES





Lifting Eyelets

Provide a safe means of lifting the powersource.





Fan cooled design

Provides efficient cooling in the most demanding environments.



Industrial Rated Components & Construction

Designed to provide long lasting, trouble free performance.



Industrial Running Gear

Design for a variety of terrain. New rubber tires provide smooth and easy maneuverability.


Easy-to-Use Interface

Allows the operator to select the correct welding amperage range to suit the desired electrode.


Ergonomic Design

Angled controls & low friction rack system make reading and adjustment of welding current easier.


Quick Connect Weld Terminals

Provides simple and convenient & robust connection of weld cables.
